| Quantity: | |
|---|---|
The valve is available in both L - type and T - type configurations, offering different flow control options. It is made of high - quality materials, including stainless steel and other alloys, to resist corrosion and wear. The valve has a low - friction design, which reduces the operating torque and improves the efficiency of the valve.
It is widely used in the marine industry for ballast water control and fuel transfer. In the offshore oil and gas industry, it is used for well - head control and subsea fluid handling. It is also used in the chemical processing industry for handling hazardous and flammable fluids. In the power plant, it is used for steam and condensate flow control.
Q: What is the fire - safe design feature of the valve?
A: The fire - safe design typically includes a secondary sealing mechanism that comes into play when the primary soft seat material is damaged by fire. This helps to prevent leakage and maintain the integrity of the valve during a fire emergency.
Q: Can the valve be operated remotely?
A: Yes, the valve can be equipped with an actuator, such as a pneumatic, hydraulic, or electric actuator, which allows for remote operation and control. This is useful in applications where access to the valve is difficult or when automated control is required.
Q: How do I test the 3 - Way Ball Valve for proper operation?
A: You can perform a visual inspection to check for any signs of damage or leakage. You can also test the valve by applying pressure and checking the flow through each port to ensure that the valve is functioning properly and that the sealing is tight.
A.USAGE
The three-way/four-way ball valve is used for switching, converging and diverging pipeline medium flow direction. It is widely applied in metallurgy, mine, petroleum, chemical industry, electric power, light industry, shipping industry and automation control systems, suitable for service conditions such as switching, mixing and diverging of fluid, gas and power.
B.STRUCTURAL CHARACTERISTICS
The three-way/four-way ball valve is provided with reliable sealing and smooth flow channel so as to ensure accuracy of opening and closing through small fluid pressure loss and stable flow channel. According to the forms of flow channel, the valve can be classified into "Y" pattern three-way ball valve, "L" pattern three-way ball valve, "T" pattern three-way ball valve and "LL" pattern four-way ball valve.
"Y" pattern Three-way Ball Valve(q42 Type)
The form of flow channel is "Y" pattern, which can effectively realize switching from service condition 1 to service condition 2. It is mainly used for switching "Y" pattern pipeline flow direction.
"L" Pattern Three-way Ball Valve(q44 Floating Type,Q49 Trunnion Type)
The "L" pattern therr-way ball valve is used for switching pipeline medium flow direction. It can connect two flow channels that are vertical with each other. The ordinary "L" pattern floating three-way ball valve may not be suitable for some service conditions, which shall be paid special attention to when users select it.
C.STRUCTURAL FEATURES
"T" Pattern Three-way Ball Valve(q45 Floating Type,Q48 Trunnion Type)
The "T" pattern three-way ball valve is used for switching, converging and diverging medium flow direction. The "T" pattern ball channel can make three channels connect with each other or two of them connect with each other to realize two, three of found kinds of functions. Different valve designs are adopted to realize different functions. Therefore, users shall make detailed descriptions to the service requirements when selecting and ordering the "T" pattern three-way ball valve, so that our company can make designs and configurations correctly. The ordinary "T" pattern floating three-way ball valve may not be suitable for some service conditions, which shall be paid special attention to when users select it.
D."LL" Pattern Four-way Ball Valve
The "LL" pattern four-way ball valve is provided with four seats to realize switching from service condition 1 to service condition 2. It can simultaneously switch the flow direction of two media, which realizes the effect of multiple functions in one valve with convenience and swiftness.
E.The work form is shown as follows:
1. When A(C) is the inlet, the two connections of A →B(C→D) or A→C(C→A) can be realized.
2. A cannot be realized.
3. A→D(C→B) or D→A(B→C) is impossible.
| Name | T Type Hydraulic Three Way Ball Valve |
| 1.Size | 1/2"-16" |
| 2.Pressure | 150LB-900LB,1.6MPa-10MPa |
| 3.Material | WCB, LCB, 304/CF8, 316/CF8M, 316L/CF3M, A105,etc |
| 4.Temperature | -20-350 |
| 5.Design Standard | API, JIS, DIN or manufacturing according to your requirements |
| 6.Operation | Pneumatic |
Production process
Certificates & Test reports
Packing&Shipping
