It comes with a wide range of options in terms of size, pressure rating, and seat material. The valve's design is optimized for low - flow resistance, ensuring efficient fluid transfer. The ring seat is designed to provide a tight seal even under high pressure and temperature variations. The valve is available in different end connections such as flanged, socket - weld, and butt - weld, allowing for easy integration into existing piping systems. The actuator options are also diverse, enabling seamless automation of the valve operation.
In the mining industry, the Ring Type Ball Valve is used for the control of slurry and wastewater. Its wear - resistant properties make it suitable for handling abrasive fluids. In the heating, ventilation, and air conditioning (HVAC) systems, it is used for the control of chilled water and hot water flow. The valve's ability to provide accurate flow control helps to optimize the energy efficiency of the HVAC system. In the food processing industry, the soft - seated Ring Type Ball Valve is used for the handling of food products such as milk, juice, and sauces. Its hygienic design and smooth interior surface prevent product buildup and ensure easy cleaning.
Q: How do I select the appropriate seat material for my Ring Type Ball Valve?
A: The selection of the seat material depends on several factors such as the type of fluid (corrosive, abrasive, or clean), the operating temperature, and the pressure. For corrosive fluids, a soft - seat made of a chemically resistant polymer like PTFE may be suitable. For high - temperature and high - pressure applications, a metal - to - metal seat would be a better choice.
Q: What is the expected lifespan of a Ring Type Ball Valve?
A: The lifespan of the valve depends on various factors such as the operating conditions, the frequency of operation, and the quality of maintenance. Under normal operating conditions and with proper maintenance, a Ring Type Ball Valve can last for many years. However, in harsh environments or with frequent operation, the valve may need to be replaced or serviced more frequently.
Q: Can the Ring Type Ball Valve be used for gas applications?
A: Yes, the Ring Type Ball Valve can be used for gas applications. Depending on the gas properties and the operating conditions, the appropriate seat material and valve construction should be selected to ensure safe and reliable operation. For example, metal - to - metal seats may be preferred for high - pressure gas applications.
MAIN FEATURES
Patented Velan ring valves are an intrinsically safe design. The ring valve has no seats. It is a throttling valve. As a result, it does not require a mechanical stop in order to avoid full closure and the resulting drum overpressurization.
Design Features
Steam purges: Steam purges to bellows and body area ensure the valve cavities are kept free of coke buildup.
Excellent throttling characteristics: In the "maximum obstruction" position, the valve provides a pressure drop equal to a butterfly valve's set at 15° open.
Automation: The electric, hydraulic or pneumatic actuator is selected in function of coker service. A large torque safety factor ensures the valve will cycle under the most stringent conditions. When selecting actuators, special attention is paid to the coker deck environment.
Top entry ball valve is mainly used in pipeline and industry system and it has a top entry and on line maintenance function. It has a lot of advantages, such as small fluid resistance,simple structure, small volume, light weight, reliable saaling, convenience for operation and maintenance, open and close quickly, as well as start and close flexibly.
1. One piece body
One piece body is used for the body to guarantee sufficient strength and rigidity under maximum rated operating pressure. The internal parts of valve are carefully designed and selected to ensure reliability under all kinds of operating condition. Enough margin wall thckness and adaptation of high strength connective bolts are convenient for valve maitenance and sufficiency to support the stress from piping.
2. Top entry
Its most difference from common ball valve is that its maintenance can be made on pipe line and without dismounting from the pipe line. The back space seat structure is adopted for the seat and the rear portion of seat retainer is oblique angle to prevent accumulation of impurity from affecting back space of seat.
3. Low operation torque
Top entry series ball valve has a trunnion mounted ball, whose surface is ground, polished and hard face treated. The ball and stem is integrated, sliding bearing is installed on the external bore so that the friction radius is small and operation torque is very low.
4. Emergency sealing
Compound injection holes are designed and compound injection valves are installed at locations of stem/cap and body support of side valve. When sealing of stem or seat is damaged to induce leakage, the compound can be used to do the second time sealing. A concealed check valve is installed in side of each compound injection valve to prevent compound from out flowing due to the action of transmitter substance. The top of the compound injection valve is the connector for fast connection with compound injection gun.
5. Reliable sealing
The seat sealing is formed by seat sealing and metal retainer component. The seat retainer floats axially and low pressure sealing of valve seat is reached by pre-pressure of spring. In addition, the piston effect of valve seat is designed reasonably, which realized high pressure sealing by the pressure of operating medium and realize the interception of retainer to form the sealing of the body. The expansion graphite ring is designed to realize sealing under fire condition.
6. Double block&bleed(DBB)
When ball is full open or close position, the transmitter substance in center cavity of body can be released by drainage and emptying devices. In addition, the over loaded pressure in the center cavity of valve can be released to low pressure end by self relief seat.
7. Anti-static and fire safe design
The fire prevention design of valve meets the requirement in API6FA/API607 standard and the design of the anti-static conforms to regulations in API6D and BS5351.
8. Extension stem
For the underground installed valve, the stem can be lengthened and for the convenience of operation the corresponding compound injection nozzle and drainage valve can be extended to the top of valve.
9. Various driving types
The top pad of valve designed according to ISO 5211, which is convenient for connection and exchange of various drivers. The common driving types are manual, electrical, pneumatic and pneumatic/hydraulic.
| Brand: | Yuefeng |
| Applicable Media: | Water, Oil, Gas, Nitric Acid, Acetic Acid |
| Certification: | CE/RoHS/ISO9001-2008 |
| Original | Lishui, Zhejiang Province |
| Packing: | Plastic Bag, Carton & Plywood Case/According to customers' requirement. |
| Payment: | T/T, L/C, D/P, Western Union. |
| Port: | Shenzhen, Customers' Request |
| Delivery Time: | Within 15days after receiving T/T deposit Payment |
| Term of Delivery: | EXW/FOB/CNF/CIF, Customers' Request |
Production process
Certificates & Test reports
Packing&Shipping
