MAIN FEATURES
The three-way/four-way ball valve is used for switching, converging and diverging pipeline medium flow direction. It is widely applied in metallurgy, mine, petroleum, chemical industry, electric power, light industry, shipping industry and automation control systems, suitable for service conditions such as switching, mixing and diverging of fluid, gas and power.
STRUCTURAL CHARACTERISTICS
The three-way/four-way ball valve is provided with reliable sealing and smooth flow channel so as to ensure accuracy of opening and closing through small fluid pressure loss and stable flow channel. According to the forms of flow channel, the valve can be classified into "Y" pattern three-way ball valve, "L" pattern three-way ball valve, "T" pattern three-way ball valve and "LL" pattern four-way ball valve.
"Y" pattern Three-way Ball Valve(q42 Type)
The form of flow channel is "Y" pattern, which can effectively realize switching from service condition 1 to service condition 2. It is mainly used for switching "Y" pattern pipeline flow direction.
| Pipe Size | 1/4" NPT female |
| Port Size | Full Port, Orifice 0.45 inches, Cv 8 |
| Pressure (Max) | 1000 PSI, vacuum up to 29inHg |
| Working Temperature of Assembly | 0-180 °F (media 0-300 °F with optional valve mounting kit) |
| Valve Body | 316 stainless steel CF8M |
| Ball/Stem | 316 stainless steel |
| Stem Seals | PTFE (reinforced Teflon)/ Viton |
| Ball Seats | PTFE (reinforced Teflon) |
| Valve Rated Temperature | 356 °F maximum |
| Cycle Time | Approx. 1 second per 90° rotation |
| Air Pilot Pressure | 80-120 PSI |
| Air Connections | 1/8" NPT (plus NAMUR pad for solenoid valve) |
| Actuator Seals | NBR |
| Weight | 2KG |
| Brand: | Yuefeng |
| Applicable Media: | Water, Oil, Gas, Nitric Acid, Acetic Acid |
| Certification: | CE/RoHS/ISO9001-2008 |
| Original | Lishui, Zhejiang Province |
| Packing: | Plastic Bag, Carton & Plywood Case/According to customers' requirement. |
| Payment: | T/T, L/C, D/P, Western Union. |
| Port: | Customers' Request |
| Delivery Time: | Within 15days after receiving T/T deposit Payment |
| Term of Delivery: | EXW/FOB/CNF/CIF, Customers' Request |
More Details
Warranty
Warranty 1 year
Great quality products
We stand behind the quality of our products 100%
All of our items come with a warranty to give you a peace of mind.
New Guaranteed: All of our items are in new condition in OEM or Original packing.
Package
Our package method is in perfect condition, or according customized.
Payment
MOQ: Customer design
We usually accept T/T(wire transfer), Western Union
Trade Currency: USD or RMB
TT 30% deposit in advance,70% balance paid before shipment.
(sample order) T/T / Western union 100% at sight
Delivery
Shipment term: CIF/CFR/FOB Shanghai China, EXW Lishui China
Shipment date: 10-30 days after receiving the deposit
We will ship your items by sea, by air(DHL,UPS,FedEx,TNT, EMS,ARAMEX)
5.Contact information
Call the YFV Customer Team:
We are here for you 24 hours a day-365 days a year.
Email us
We look forward to helping you with your inquiry. We respond to email to message
in the order that they are received, and will respond to your email as quickly as possible.
7.Connect With Live Help:
Ask your question right now with trade manager.
Production process
Certificates & Test reports
Packing&Shipping
FAQ
Q: Are you a trading company or a manufacturer?
We are a manufacturer with a 13,000 square metre factory.
Q: Can you provide assembly drawings?
Yes, we will provide the relevant drawings as soon as possible if you need them.
Q: How do you guarantee the quality of your products?
A: Before the products leave the factory, our quality inspectors will inspect each product before shipment to ensure the pass rate.
Q: Can you produce different standard valves according to customers' requirements?
A: Yes, please provide specific details, such as model, size, pressure, material and so on.
Q: How long is your delivery time?
A: Usually 15-30 days, it depends on the order quantity and our storage.
